EPCUBE Square Pole Tomb Type Electro Permanent Magnetic Chuck

Price 560000.0 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

EPCUBE Square Pole Tomb Type Electro Permanent Magnetic Chuck Specification

Application
Industrial

Frequency
50/60 Hertz (HZ)

Voltage
220/380/400/480 Volt (v)

Magnet Category
Permanent Magnets

Shape
Rectangle

Size Range
430x300x535mm (LxWxH)

Color
Silver

EPCUBE Square Pole Tomb Type Electro Permanent Magnetic Chuck Trade Information

Minimum Order Quantity
1 Piece

Payment Terms
Cash in Advance (CID)

Supply Ability
10 Pieces Per Month

Delivery Time
5-7 Days

Main Domestic Market
All India

About EPCUBE Square Pole Tomb Type Electro Permanent Magnetic Chuck

The EPCUBE Square Pole Tomb Type Electro Permanent Magnetic Chuck is a cutting-edge solution designed for industrial applications requiring robust magnetic performance and precision. With a rectangular shape and sleek silver finish, this chuck boasts dimensions of 430x300x535mm (LxWxH). It operates efficiently on a variety of voltage options, ranging from 220V to 480V, ensuring compatibility with diverse setups. The chuck uses permanent magnets powered by electro-magnetic technology, ensuring stable clamping and reliable magnetic force even during power loss. Its frequency of 50/60 Hz provides optimized operations for industrial environments that demand precision and high durability. With a focus on safety, performance, and longevity, this product is an asset for industries seeking efficient magnetic handling and machining solutions.

Patented full steel Top surface.
High induction of magnetic flux.
High & uniform clamping power throughout the bed.
Variable magnetic power possible.
Perfect safety in case of power failure.
2 or 4 or multiple magnetic face.
Unobstructed movement of tools during machining as all five faces of the job can be machined in the same setting.
Drastically reduces the setup time and machining of the work pieces.
Total magnetic surface used for clamping giving better machining accuracy as reducing chattering.
100% Leak Proof.
Clamping force for EPCUBE 50 >350 kg/ pole.
Clamping force for EPCUBE 75 > 790 kg/ pole

Art No.	W	L	T	H	Pole Size	Poles on each Face	Controller
13116.01	300	430	125	535	75	24	93101.09
13107.01	327	337	125	442	50	9	93101.09
13107.03	415	601	125	706	50	24	93101.09
13107.02	415	425	125	530	50	16	93101.09
13116.04	420	590	125	695	75	48	93101.09
13116.06	480	590	125	695	75	56	93101.09
13116.08	590	600	125	705	75	72	93101.09
13116.07	590	480	125	585	75	56	93101.09
13107.04	591	815	125	920	50	48	93101.10
13116.11	600	990	125	1095	75	126	93101.09
13116.10	600	750	125	855	75	90	93101.09
13107.05	601	679	125	784	50	42	93101.09
13107.07	767	1029	125	1134	50	80	93101.10
13107.06	767	590	125	695	50	64	93101.10

FAQs of EPCUBE Square Pole Tomb Type Electro Permanent Magnetic Chuck:

Q: What are the main dimensions of the EPCUBE Square Pole Tomb Type Magnetic Chuck?

A: The chuck measures 430x300x535mm (LxWxH), making it suitable for industrial applications requiring precision and durability.

Q: What type of magnet category is used in this chuck?

A: The product uses permanent magnets for stable and consistent magnetic performance.

Q: What is the operational frequency of the chuck?

A: The magnetic chuck operates at 50/60 Hertz, ensuring compatibility with industrial frequency standards.

Q: Is the product compatible with different voltage levels?

A: Yes, the chuck is compatible with voltage ranges of 220V, 380V, 400V, and 480V.

Q: What is the primary application of this magnetic chuck?

A: The EPCUBE Square Pole Tomb Type Electro Permanent Magnetic Chuck is ideal for industrial applications requiring precise clamping and machining solutions.
