EFINE Round Fine Pole Round Magnetic Chuck

Send Inquiry

Request To Call Back

EFINE Round Fine Pole Round Magnetic Chuck

Name: EFINE Round Fine Pole Round Magnetic Chuck
Brand: Magnet Revolution Private Limited
Price: 34000.0 INR
Availability: InStock

Price 34000.0 INR/ Piece

Get a Price/Quote

MOQ : 1 Number

EFINE Round Fine Pole Round Magnetic Chuck Specification

Surface Finish
Precision ground

Composite
Steel, Brass and Magnets

Voltage
110V / 220V

Magnet Grade
N35 or Equivalent

Frequency
50Hz / 60Hz

Application
Precision Grinding and Milling

Power
Electromagnetic / Permanent

Material
Steel Body, Brass Pole Pieces

Power Supply
AC

Product Type
Magnetic Chuck

Magnet Category
Fine Pole

Magnet Type
Electromagnetic / Permanent

Shape
Round

Size Range
150mm to 600mm diameter

Weight
Varies by size (e.g., 18 kg for 200mm, 40 kg for 300mm)

Color
Machined Grey / Silver

Usage & Applications
Surface grinding, cylindrical grinding, lathe machine attachments

Capacity
Up to 200 kg clamping force

Life Span
Long operational lifespan due to sturdy construction

Operating Temperature
Up to 80C

Control
On/Off Switch Lever

Top Plate Thickness
10-14mm (dependent on chuck size)

Clamping Force
Up to 100 N/cm2

Water Resistance
Yes, suitable for coolant operations

Maintenance
No frequent maintenance required

Pole Pitch
1.5+0.5 mm (Fine pole spacing for thin/small workpieces)

EFINE Round Fine Pole Round Magnetic Chuck Trade Information

Minimum Order Quantity
1 Number

Payment Terms
Cash Advance (CA)

Supply Ability
10 Per Month

Delivery Time
6 Week

Main Export Market(s)
Western Europe, Middle East, Australia, South America, Eastern Europe, Central America, North America, Asia

Main Domestic Market
All India

About EFINE Round Fine Pole Round Magnetic Chuck

suitable for all types of rotary surface grinding machines ideal for small and thin components all brass metal steel laminated top plate high resistant to coolant/corrosion it can be mounted on machine by fitting the adapter to the tapped holes provided in the back side.

Versatile Precision for Grinding Applications

Designed for exacting work, the EFINE Round Fine Pole Magnetic Chuck is perfect for surface grinding, cylindrical grinding, and lathe machine setups. Its fine pole spacing guarantees reliable clamping for even the smallest workpieces, ensuring accuracy in every machining process. The robust build and finely ground top plate enhance overall functionality.

Durable Construction for Demanding Environments

Manufactured using heavy-duty steel and brass with integrated high-grade magnets, this magnetic chuck withstands intense operational demands. Its water resistance allows operation with coolants, while a high working temperature threshold (up to 80C) supports continuous production cycles. Precision finishing guarantees consistent performance over a long service life.

Effortless Operation and Minimal Maintenance

The integrated on/off switch lever ensures quick setup and release of workpieces, optimizing workflow. The stable construction requires little routine maintenance, reducing downtime. With a range of available diameters and both AC power supply and permanent magnet styles, the chuck adapts easily to diverse workshop needs.

FAQs of EFINE Round Fine Pole Round Magnetic Chuck:

Q: How does the EFINE Round Fine Pole Magnetic Chuck enhance precision in grinding operations?

A: The fine pole pitch of 1.5+0.5 mm provides uniform magnetic force distribution, allowing even the smallest or thinnest workpieces to be securely clamped. This ensures dependable holding power and minimizes workpiece movement, resulting in superior accuracy during surface or cylindrical grinding.

Q: What types of workpieces and machining tasks is this magnetic chuck best suited for?

A: This magnetic chuck is ideal for thin or small workpieces, commonly used in precision surface grinding, cylindrical grinding, and as attachments for lathe machines. It performs excellently in settings requiring secure, precise, and repeatable clamping.

Q: When should I use coolant with this magnetic chuck, and is it water-resistant?

A: The EFINE Round Magnetic Chuck is specifically designed to be water-resistant, making it perfectly safe for use in environments with coolant or lubricant applications, especially during grinding and milling operations where cooling is essential.

Q: Where can I install and operate the magnetic chuck?

A: The chuck is adaptable to a range of grinding machines, milling machines, and lathes, and can be integrated into workshops, toolrooms, or manufacturing facilities requiring precision finishing and reliable clamping across different machine brands.

Q: What is the typical maintenance process, and does the chuck require frequent servicing?

A: The chuck boasts a maintenance-free design thanks to its sturdy construction. Routine wiping and checking for debris on the surface are typically sufficient for optimal performance, reducing the need for frequent maintenance or adjustments.

Q: What are the main benefits of choosing an EFINE magnetic chuck?

A: Primary benefits include powerful and consistent clamping, water and coolant resistance, user-friendly operation, low maintenance, and a long operational lifespan. Its availability in both electromagnetic and permanent magnet models caters to a variety of workshop requirements.
